| Camera |
| Image Sensor |
1/2.8” Progressive Scan CMOS |
| Effective Pixels |
2592(H)×1520(V) |
| Electronic Shutter |
Auto/Manual, 1/5 ~ 1/20,000s |
| Min. illumination |
Color: 0.05 Lux @ (F1.2, AGC ON) ,
B/W: 0 Lux @ (IR LED ON) |
| S/N Ratio |
55 dB |
| Day/Night |
Auto(ICR) |
| Wide Dynamic Range |
WDR (100 db) |
| IR Range |
Up to 30 m (98.4 ft) |
| IR On/Off Control |
Auto/Manual |
| Pan/Tilt/Rotation Range |
Pan: 0˚ ~ 355˚, Tilt: 0˚ ~ 80˚, Rotation: 0˚ ~ 355˚ |
| Lens |
| Focal Length |
Motorized focus |
| Iris |
Fixed Iris |
| Focal Length |
2.7 ~ 13.5 mm |
| F Number |
F1.6 |
| Angle of View |
H: 98.5° ~ 27.8°, V: 71° ~ 20° |
| Video |
| Video Compression |
H.265, H.264, MJPEG |
| Max. Resolution |
4MP (2592×1520) |
| Streaming Capability |
3 Streams |
| Stream/Frame Rate |
Stream1: 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720 @ 25/30fps
Stream2: D1, VGA, 640×360, CIF, QVGA @ 25/30fps
Stream3: VGA, CIF, QVGA @ 25/30fps |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
Stream1: 100kbps~16Mbps
Stream2: 10kbps~6Mbps
Stream3: 10kbps~3Mbps |
| White Balance |
Auto |
| Gain Control |
Auto/Manual |
| Mirror |
Support |
| Smart IR |
Support |
| Noise Reduction |
2D/3D DNR |
| Image Enhancement |
HLC / BLC / Anti-shake / WDR |
| Region of Interest |
Off/On (8 Zone, Rectangle) |
| Motion Detection |
Support |
| Privacy Masking |
Support |
| Audio |
| Compression |
G.711, RAW_PCM |
| Bit Rate |
8kbps, 16kps, 64kbps |
| Network |
| Protocols |
IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL |
| Interoperability |
ONVIF, SDK, CGI |
| Streaming Method |
Unicast |
| Max. User Access |
10 Users |
| Web Viewer |
<IE11, Chrome, Firefox, Microsoft Edge |
| Interface |
| Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio |
1ch Input, 1ch Output |
| Alarm |
1ch Input, 1ch Output |
| Reset Button |
Support |
| Storage |
Built-in Micro SD slot, up to 256G |
| Electrical |
| Power Supply |
DC12V/POE (IEEE 802.3af) |
| Power Consumption |
Max 8.5 W |
| Operating Temperature |
-40°C ~ 55°C (-40°F ~ 131°F ) |
| Operating Humidity |
Less than 90% RH |
| Ingress Protection |
IP66, IK10 |
| Certifications |
CE/FCC |
| Casing |
Metal |
| Dimensions |
φ130 × 112mm (φ5.12″ × 4.41″) |
| Net Weight |
0.8 kg (1.76 lb) |
