| Camera |
| Model | PH-3102 2MP Pinhole Lens IR Camera |
| Image Sensor | 1/2.7” STARVIS Progressive Scan CMOS Sensor |
| Lens | 3.7mm Pinhole Lens |
| Horizontal View Angle | 92º |
| Minimum Illumination | 0.1 Lux @ F1.2, (Color)
0 Lux (IR LED On) |
| IR Distance | 1M |
| Shutter Speed | 1/30s – 1/10,000s |
| WDR | True WDR (120 dB) |
| Noise Reduction | 3D (DNR) |
| Day / Night Function | Mechanical IR Cut Filter |
| Video |
| Video Compression | H.265, H.264, & MJPEG |
| Image Resolution | 5MP (2592 x 1944) @ 30fps |
| Streams | First: (1920 x 1080) @ 30fps
Second: (720 x 480) @ 30fps
Third: (320 x 240) @ 30fps |
| S/N Ratio | 41dB |
| Image Settings | Brightness, Contrast, Sharpness, Day & Night,
AWB, Auto Exposure, Privacy Mask, DSS,
Corridor View, Mirror / V-Flip, Etc. |
| Audio |
| Audio Interface | Input / Output |
| Audio Compression | G.711 |
| Audio Streaming | Two-Way (Full Duplex) |
| General |
| ONVIF Compliant | 2.4 (Profile S & T) |
| PigtailConnections | IEEE 802.3af (PoE) |
| Power Consumption | 5.5W (Max) |
| Memory | Micro SD Card (Not Included) |
| LED Indicators | Power (Red) & Power / Network Connection (Green) |
| Power PoE /
Terminals | PoE; DC12V @ Less Than 5.5W |
| |
| Temperature | -40° ~ 140° F |
| Humidity | 95% (Non-Condensing) |
| Dimensions in Inches (H x W x D) | 0.95 x 2.6 x 4.21 in. |
| Weight in Ounces | 8.68 oz. (Including Cable & Sensor Module) |
| Weather Proof | – |
| Vandal Proof | – |
| Certification | CE / FCC |
